Equipments, Laboratories and Softwares
Equipments
The department is equipped with the following facilities:
- 2-Channel, Digital Storage Oscilloscopes
- 2-Channel, Arbitrary Function Generators
- Bench Top, Digital Multimeter
- Bench Top, Variable Magnitude Three Output DC Power Supply
- Three-Phase Programmable AC Source
- Three-Phase Power Quality Analyzer
- 4 Isolated Channels Digital Storage Oscilloscopes
- Insulation Tester
- Earth Ground Tester
- Leakage Current Clamp Meter
- Digital Soldering Station
- Lab Server Monitoring Station
- Induction Motor Trainer Kit
- DC Machine
- AC/DC Load
- DC Power Supply
- Current clamp meter
- Thermal Evaporator Unit
- Solar Simulator
- Hardware-in-loop (HIL) Simulator
- FPGA kits for Embedded Circuits
- Photodetector Characterization Setup
- Electrochemical Workstation
- Source Meter
- Broadband Spectrometer
- Broadband Light Source
- Cell Capacity Tester (16 Points)
- Active Cell Balancer
- USRP N210 with 50 MHz - 2.2 GHz, 40 MHz BW, Triband/Dualband Vertical Antenna
- 4 -Wheeler EV Motor Drivetrain, Live Experimental Setup with Data Acquisition
- Battery, Smart BMS with CAN Protocols Training Setup
- Pneumatic Spot Welding for Prototyping
- EV Charging Station
- 6-Ø, 5HP IPMSM Motor with DC Machine Load Setup
- PCB Itching Machine
- AC / DC distribution Box
- 6 phase 3 level NPC inverter
- DS1104 R&D Controller Board
- 3-level 3-phase VSI Setup with PWM control
- 3-phase inverter setup with different PWM techniques
- PMSM & BLDC Motor Setup with Control Panel
Frequency Modulation and Demodulation
8051 Micro Controller
Phase Modulation and Demodulation
Amplitude Modulation and Demodulation
8085 Microprocessor Monitor
Thin Film Deposition (Thermal Evaporation)
Hardware in Loop (Scalexio)
Five Phase Voltage Source Inverter
Traffic Light Controller
Dual Digital Analog Converter
Stepper Motor Interface
Digital Trainer Kit
Field Programmable Gate Arrays Kit
Analog and Digital Experimental System
Hardware and Software Setup
Softwares
- Silvaco TCAD
- COMSOL Multiphysics
- Xilinx
- OrCAD
- Electrical Power System Simulator (EPSS)
- Virtual ECU Offline Simulator (VEOS)
- Automotive Simulation Models (ASM)
